Tonic Audio™ Haven |
TerraMaster™ F8 SSD Plus |
QNAP™ TBS-H574 |
Synology™ FlashStation FS2500 |
|---|---|---|---|---|
|
Price
| ||||
| MSRP | $3,995 | $2,940 | $4,400 | $5,660 |
| Spec'ed storage size
Since each product offers multiple storage options, we specified the ones that come closest to a comparable Haven size. We also use the advertised size given by each company here, not the usable storage size. | 16TB | 16TB | 16TB | 16TB |
|
Storage Engine
| ||||
| Raw storage | 20TB | 20TB | 20TB | 16TB |
| Usable storage
Many products advertise their storage sizes as raw amounts, not actually usable storage, when you add in important features like drive-failure redundancy. This row shows actual usable storage in each porduct's default configuration. Most products, including Haven, allow you to increase the failed-drive redundancy, but at a lower usable storage amount. | 16TB | 16TB | 16TB | 12TB |
| Redundancy
This shows the number of storage drives that can fail without losing data in the product's default configuration. Most products, including Haven, allow you to increase the failed-disk redundancy, but at a lower usable storage amount. | 1 drive | 1 drive | 1 drive | 1 drive |
| Throughput |
6GB/s write / 6GB/s read |
1GB/s write / 1GB/s read |
3GB/s write / 3GB/s read |
4GB/s write / 2GB/s read |
|
Connectivity
| ||||
| Network ports | x2 10GbE | x1 10GbE | x1 10GbE, x1 2.5GbE | x2 10GbE, x2 1GbE |
| Wi-Fi ports | 2Gb/s Wi-Fi 7 (optional) | Not included | Not included | Not included |
| Thunderbolt 5™ ports | x2 80Gb/s | Not included | Not included | Not included |
| USB 4 ports | Not included | Not included | Not included | Not included |
| USB 3 ports | x2 20Gb/s, x2 10Gb/s | x3 10Gb/s | x2 20Gb/s, x2 10Gb/s | x2 5Gb/s |
|
Audio Capabilities
| ||||
| Line level outs | Included | Not included | Not included | Not included |
| DNR
The dynamic range of the digital-analog converter (DAC). | +130dB | Not included | Not included | Not included |
| THD
The total harmonic distortion of the digital-analog converter (DAC). | -126dB | Not included | Not included | Not included |
| THD+N
The total harmonic distortion + noise of the digital-analog converter (DAC). | -120dB | Not included | Not included | Not included |
| Max bitrate | 32 | Not included | Not included | Not included |
| Max sample rate | 768kHz | Not included | Not included | Not included |
| DSD1024 support | Included | Not included | Not included | Not included |
| Digital outs | Included | Not included | Not included | Not included |
| Headphone outs | Included | Not included | Not included | Not included |
|
Physical Specs
| ||||
| Form factor | 1U Rack / Desktop | Desktop | Desktop | 1U Rack |
| Noise level @ 1m
The maximum sound pressure level of the unit at full load measured 1 meter away. | max 35 dB(A) | max 35 dB(A) | max 35 dB(A) | max 58 dB(A) |
|
Software
| ||||
| Cloud storage sync
Support for automatically syncing with major cloud storage providers including Dropbox, Google Drive, and Microsoft OneDrive. | Included | Included | Included | Included |
| Private folder sharing
Support for sharing private folders remotely with collaborators or clients. | Included | Not included | Included | Included |
| Remote access | Included | Included | Included | Included |
| Collaborator feedback | Included | Not included | Not included | Not included |
| Audio project audition | Included | Not included | Not included | Not included |
|
Offsite Backup
| ||||
| Vendor offered | Included | Not included | Included | Included |
| Encrypted before backup | Included | Not included | Included | Included |
| $ per TB per month | $6 | Not included | $7 | $10 |
| 3rd-party backup
For products offering offsite backup, are 3rd party backup services available? These are services such as Amazon AWS S3/Glacier, Backblaze B2, and others. | Included | Included | Included | Included |
|
Support
| ||||
| Included | Included | Included | Included | |
| Chat | Included | Included | Included | Not included |
| Phone | Included | Included | Not included | Included |
| Community forum | Included | Not included | Included | Not included |
